MS3476L14-9S
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Circular MIL Spec Connector ST PLUG 9P SZ 12 4 AND 20 SOCKET
PDF
/
Buying Options
Total Price: USD $61.94
Unit Price: USD $61.9432
≥1 USD $61.9432
≥10 USD $56.84448
≥100 USD $54.657856
≥500 USD $52.835904
≥1000 USD $49.920816
Inventory: 106
Minimum: 1
-
+
Technical Details
Compliance
Ratings Environment Resistant, IP67
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Technical
Plating Electroless Nickel
Environmental Characteristics ENVIRONMENT/FLUID/IMMERSION/MOISTURE RESISTANT
Backshell Type SOLID
Empty Shell NO
Contact Gender Female
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 9
Shell Size - Insert 14-9
Shell Finish Electroless Nickel
Military Standard MIL-DTL-26482
Current Rating 23A
Ingress Protection Environment Resistant
Shielding Unshielded
Orientation N (Normal)
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
Applications Aviation, Industrial, Military
Color Silver
Number of Positions 9 (Power)
Connector Type Plug, Female Sockets
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Coupling Nut
Series Military, MIL-DTL-26482 Series II
Published 2010
Packaging Bulk
Operating Temperature -65°C~200°C
Physical
Shell Material Aluminum
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 16 Weeks
