RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description Circular Connector
PDF
/
Buying Options
Total Price: USD $93.75
Unit Price: USD $93.751946
≥1 USD $93.751946
≥10 USD $88.445228
≥100 USD $83.438893
≥500 USD $78.715936
≥1000 USD $74.260313
Inventory: 7954
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 16 Weeks

Physical

Contact Material Copper Alloy
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Aluminum

Technical

Operating Temperature -65°C~200°C
Packaging Bulk
Published 2010
Series Military, MIL-DTL-26482 Series II
Feature Coupling Nut
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Plug, Female Sockets
Number of Positions 39 (Power)
Color Black
Applications Aviation, Industrial, Military
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Orientation N (Normal)
Shielding Unshielded
Ingress Protection Environment Resistant
Current Rating 13A
Military Standard MIL-DTL-26482
Shell Finish Black Anodized
Shell Size - Insert 20-39
Number of Contacts 39
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Gender Female
Empty Shell NO
Backshell Type SOLID
Plating Anodized

Dimensions

Contact Finish Thickness - Mating 50.0μin 1.27μm

Compliance

Radiation Hardening No
RoHS Status Non-RoHS Compliant
Ratings Environment Resistant, IP67
