MS3476A12-3S
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Connector
PDF
/
Buying Options
Total Price: USD $17.47
Unit Price: USD $17.468
≥1 USD $17.468
≥10 USD $16.94
≥100 USD $16.456
≥500 USD $15.7696
≥1000 USD $15.5496
≥3000 USD $15.136
Inventory: 48
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Aluminum
Technical
Operating Temperature -65°C~200°C
Packaging Bulk
Series Military, MIL-DTL-26482 Series II
Feature Coupling Nut
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Plug, Female Sockets
Number of Positions 3 (Power)
Color Black
Applications Aviation, Industrial, Military
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Orientation N (Normal)
Shielding Unshielded
Ingress Protection Environment Resistant
Current Rating 13A
Shell Finish Black Anodized
Shell Size - Insert 12-3
Number of Contacts 3
Mating Information MULTIPLE MATING PARTS AVAILABLE
Empty Shell NO
Backshell Type SOLID
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Ratings Environment Resistant
