MS3474L16-26S
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Circular MIL Spec Connector JAM NUT REC SKT 26P SZ 20
PDF
/
Buying Options
Total Price: USD $44.13
Unit Price: USD $44.132
≥1 USD $44.132
≥10 USD $42.812
≥100 USD $41.5712
≥500 USD $39.8376
≥1000 USD $39.292
≥3000 USD $38.2448
Inventory: 169
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Contact Plating Gold
Mount Bulkhead, Front Side Nut, Jam Nut, Panel
Mounting Type Panel Mount
Mounting Feature Bulkhead - Front Side Nut
Shell Material Aluminum
Technical
Operating Temperature -65°C~200°C
Packaging Bulk
Published 2006
Series Military, MIL-DTL-26482 Series II
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Receptacle, Female Sockets
Number of Positions 26 (Power)
Max Operating Temperature 200°C
Min Operating Temperature -65°C
Color Silver
Applications Aviation, Industrial, Military
Voltage - Rated 600V
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
Orientation N (Normal)
Shielding Unshielded
Ingress Protection Environment Resistant
Current Rating 7.5A
Military Standard MIL-DTL-26482
Shell Finish Electroless Nickel
Shell Size - Insert 16-26
Number of Contacts 26
Contact Gender Female
Plating Electroless Nickel
Wire Gauge (Max) 24 AWG
Wire Gauge (Min) 20 AWG
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Ratings Environment Resistant, IP67
