MS3472W12-3PY
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Connector
PDF
/
Inventory: 8602
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Environment Resistant
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Length 35.68mm
Technical
Plating Cadmium
Max Current Rating 13A
Environmental Characteristics FLUID RESISTANT
Backshell Type SOLID
Empty Shell NO
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 3
Shell Size - Insert 12-3
Shell Finish Olive Drab Cadmium
Current Rating 13A
Depth 32.15mm
Ingress Protection Environment Resistant
Shielding Unshielded
Orientation Y
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
Applications Aviation, Industrial, Military
Color Olive Drab
Number of Positions 3 (Power)
Connector Type Receptacle, Male Pins
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Military, MIL-DTL-26482 Series II
Packaging Bulk
Operating Temperature -65°C~200°C
Physical
Shell Material Aluminum
Number of Pins 16
Mounting Feature Flange
Mounting Type Panel Mount
Mount Flanges, Panel, Wall
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 16 Weeks
