MS3470W12-10PX
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Olive Drab Cadmium Military MIL-DTL-26482Series II Non-RoHS Compliant Environment Resistant IP67 Circular Connector 20AWG 200C 7.5A 600V
PDF
/
Buying Options
Total Price: USD $33.48
Unit Price: USD $33.484
≥1 USD $33.484
≥10 USD $29.0136
≥100 USD $25.5992
≥500 USD $22.9064
≥1000 USD $20.0904
Inventory: 423
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Contact Plating Gold
Mount Flanges, Panel, Wall
Mounting Type Panel Mount
Mounting Feature Flange
Number of Pins 20
Shell Material Aluminum
Technical
Operating Temperature -65°C~200°C
Packaging Bulk
Published 2015
Series Military, MIL-DTL-26482 Series II
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Receptacle, Male Pins
Number of Positions 10 (Power)
Max Operating Temperature 200°C
Min Operating Temperature -65°C
Color Olive Drab
Applications Aviation, Industrial, Military
Voltage - Rated 600V
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
Orientation X
Shielding Unshielded
Ingress Protection Environment Resistant
Current Rating 7.5A
Military Standard MIL-DTL-26482
Shell Finish Olive Drab Cadmium
Shell Size - Insert 12-10
Number of Contacts 10
Contact Gender Male
Plating Cadmium
Wire Gauge (Max) 20 AWG
Wire Gauge (Min) 24 AWG
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Ratings Environment Resistant, IP67
