MS3470L14-4S
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Circular MIL Spec Connector 4P WALL MT RCP SZ 14 NARROW FLANGE SCKT
PDF
/
Buying Options
Total Price: USD $24.85
Unit Price: USD $24.8512
≥1 USD $24.8512
≥10 USD $24.112
≥100 USD $23.408
≥500 USD $22.44
≥1000 USD $22.132
≥3000 USD $21.5424
Inventory: 99
Minimum: 1
-
+
Technical Details
Compliance
Ratings Environment Resistant, IP67
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Technical
Plating Electroless Nickel
Contact Gender Female
Number of Contacts 4
Shell Size - Insert 14-4
Shell Finish Electroless Nickel
Military Standard MIL-DTL-26482
Current Rating 23A
Ingress Protection Environment Resistant
Shielding Unshielded
Orientation N (Normal)
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
Gender Receptacle
Applications Aviation, Industrial, Military
Color Silver
Min Operating Temperature -65°C
Max Operating Temperature 200°C
Number of Positions 4 (Power)
Connector Type Receptacle, Female Sockets
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Military, MIL-DTL-26482 Series II
Published 2010
Packaging Bulk
Operating Temperature -65°C~200°C
Physical
Body Material Aluminium
Shell Material Aluminum
Mounting Feature Flange
Mounting Type Panel Mount
Mount Flanges, Panel, Wall
Contact Plating Gold
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 16 Weeks
