MS3470A18-11P
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
STANDARD: MIL-C-26482COMPATIBLE CONTACT: M39029/4-111 Circular Connector
PDF
/
Inventory: 3528
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Mount Flanges, Panel
Mounting Type Panel Mount
Mounting Feature Flange
Shell Material Aluminum
Technical
Operating Temperature -65°C~200°C
Packaging Bulk
Series Military, MIL-DTL-26482 Series II
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Receptacle, Male Pins
Number of Positions 11 (Power)
Color Black
Applications Aviation, Industrial, Military
Additional Feature STANDARD: MIL-C-26482, COMPATIBLE CONTACT: M39029/4-111
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 11
Orientation N (Normal)
Shielding Unshielded
Ingress Protection Environment Resistant
Reach Compliance Code unknown
Current Rating 13A
Shell Finish Black Anodized
Shell Size - Insert 18-11
Mating Information MULTIPLE MATING PARTS AVAILABLE
Empty Shell NO
Backshell Type SOLID
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
RoHS Status Non-RoHS Compliant
Ratings Environment Resistant
