MS3459W24-12PW
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Connector
PDF
/
Inventory: 7970
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Fluid Resistant
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Technical
Environmental Characteristics ENVIRONMENT/FLUID/IMMERSION RESISTANT
Backshell Type SOLID
Empty Shell NO
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 5
Shell Size - Insert 24-12
Shell Finish Olive Drab Cadmium
Current Rating 80A
Ingress Protection Fluid Resistant
Shielding Unshielded
Orientation W
Current Rating (Amps) 23A 80A
Option GENERAL PURPOSE
Mixed Contacts YES
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Threaded
Gender Male
Applications Automotive, Military
Color Olive Drab
Number of Positions 5 (Power)
Connector Type Plug, Male Pins
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Coupling Nut, Self Locking
Series Military, MIL-DTL-5015
Published 2006
Packaging Bulk
Operating Temperature -55°C~175°C
Physical
Shell Material Aluminum
Number of Pins 12
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Plating Silver
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 16 Weeks
