MS3459LS14S-6P
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Conn MIL-DTL-5015 Circular PIN 6 POS Crimp ST Cable Mount 6 Terminal 1 Port
PDF
/
Inventory: 7030
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Contact Plating Silver
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Stainless Steel
Technical
Operating Temperature -55°C~200°C
Packaging Bulk
Published 2006
Series Military, MIL-DTL-5015
Feature Coupling Nut, Self Locking
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
Connector Type Plug, Male Pins
Number of Positions 6 (Power)
Applications Automotive, Military
Gender Male
Additional Feature STANDARD: MIL-DTL-5015
Fastening Type Threaded
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Orientation N (Normal)
Shielding Unshielded
Ingress Protection Fluid Resistant
Current Rating 13A
Shell Finish Passivated
Shell Size - Insert 14S-6
Number of Contacts 6
Mating Information MULTIPLE MATING PARTS AVAILABLE
Empty Shell NO
Backshell Type SOLID
Environmental Characteristics ENVIRONMENT/FLUID/IMMERSION RESISTANT
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Ratings Fluid Resistant
