RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description STANDARD: MIL-DTL-5015 Circular Connector
PDF
/
Inventory: 6899
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Ratings Fluid Resistant
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Material Flammability Rating Non Flammable

Dimensions

Contact Finish Thickness - Mating 50.0μin 1.27μm
Length 63.5mm

Technical

Plating Cadmium
Max Current Rating 150A
Environmental Characteristics ENVIRONMENT/FIRE/FLUID/IMMERSION RESISTANT
Backshell Type SOLID
Empty Shell NO
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 4
Shell Size - Insert 36-5
Shell Finish Olive Drab Cadmium
Current Rating 150A
Ingress Protection Fluid Resistant
Shielding Unshielded
Orientation N (Normal)
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Threaded
Additional Feature STANDARD: MIL-DTL-5015
Gender Male
Applications Automotive, Military
Color Olive Drab
Number of Positions 4 (Power)
Connector Type Plug, Female Sockets
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Coupling Nut, Firewall Usage, Self Locking
Series Military, MIL-DTL-5015
Packaging Bulk
Operating Temperature -55°C~175°C

Physical

Shell Material Steel
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Plating Silver
Contact Material Copper Alloy

Supply Chain

Factory Lead Time 16 Weeks
