Category Connectors, Interconnects / Circular Connectors
Description Circular MIL Spec Connector PLUG W/THRD COUPLING 14P SIZE 16 SOCKET
PDF
/
Buying Options
Total Price: USD $91.67
Unit Price: USD $91.6696
≥1 USD $91.6696
≥10 USD $84.12096
≥100 USD $80.885376
≥500 USD $78.189056
≥1000 USD $73.875208
Inventory: 126
Minimum: 1
-
+

Technical Details

Compliance

Ratings Fluid Resistant
RoHS Status Non-RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No

Dimensions

Contact Finish Thickness - Mating 50.0μin 1.27μm

Technical

Body Plating Cadmium
Environmental Characteristics ENVIRONMENT/FLUID/IMMERSION RESISTANT
Backshell Type SOLID
Empty Shell NO
Contact Gender Female
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 14
Shell Size - Insert 20-27
Shell Finish Olive Drab Cadmium
Military Standard MIL-DTL-5015
Current Rating 13A
Ingress Protection Fluid Resistant
Shielding Unshielded
Orientation N (Normal)
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Threaded
HTS Code 8536.69.40.20
Voltage - Rated 2kV
Gender Male
Applications Aviation, Automotive, Military
Color Olive Drab
Number of Positions 14 (Power)
Connector Type Plug, Female Sockets
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Coupling Nut
Series Military, MIL-DTL-5015
Published 2006
Packaging Bulk
Operating Temperature -55°C~175°C

Physical

Body Material Aluminium
Shell Material Aluminum
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Material Copper Alloy
