MS3452W36-5PY
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
STANDARD: MIL-C-5015COMPATIBLE CONTACT: M39029/29-216 Circular Connector
PDF
/
Inventory: 2727
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Contact Plating Silver
Mount Box, Flanges, Panel
Mounting Type Panel Mount
Mounting Feature Flange
Shell Material Aluminum
Technical
Operating Temperature -55°C~175°C
Packaging Bulk
Published 2006
Series Military, MIL-DTL-5015
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Receptacle, Male Pins
Number of Positions 4 (Power)
Color Olive Drab
Applications Automotive, Military
Gender Female
Additional Feature STANDARD: MIL-C-5015, COMPATIBLE CONTACT: M39029/29-216
Fastening Type Threaded
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Current Rating (Amps) 150A
Orientation Y
Shielding Unshielded
Ingress Protection Fluid Resistant
Shell Finish Olive Drab Cadmium
Shell Size - Insert 36-5
Number of Contacts 4
Mating Information MULTIPLE MATING PARTS AVAILABLE
Empty Shell NO
Backshell Type SOLID
Cable Opening 2.250 (57.15mm)
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Ratings Fluid Resistant
