MS3452W36-15PY
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
STANDARD: MIL-C-5015COMPATIBLE CONTACT: M39029/29-212 Circular Connector
PDF
/
Inventory: 1440
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Fluid Resistant
RoHS Status Non-RoHS Compliant
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Technical
Cable Opening 2.250 (57.15mm)
Backshell Type SOLID
Empty Shell NO
Mating Information MULTIPLE MATING PARTS AVAILABLE
Shell Size - Insert 36-15
Shell Finish Olive Drab Cadmium
Reach Compliance Code unknown
Ingress Protection Fluid Resistant
Shielding Unshielded
Orientation Y
Total Number of Contacts 35
Current Rating (Amps) 13A
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Threaded
Additional Feature STANDARD: MIL-C-5015, COMPATIBLE CONTACT: M39029/29-212
Gender Female
Applications Automotive, Military
Color Olive Drab
Number of Positions 35 (Power)
Connector Type Receptacle, Male Pins
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Military, MIL-DTL-5015
Published 2006
Packaging Bulk
Operating Temperature -55°C~175°C
Physical
Shell Material Aluminum
Mounting Feature Flange
Mounting Type Panel Mount
Mount Flanges, Panel
Contact Plating Silver
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 16 Weeks
