MS3450W28-12PY
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
STANDARD: MIL-C-5015COMPATIBLE CONTACT: M39029/29-212 Circular Connector
PDF
/
Inventory: 4611
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Fluid Resistant
RoHS Status Non-RoHS Compliant
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Technical
Backshell Type SOLID
Empty Shell NO
Mating Information MULTIPLE MATING PARTS AVAILABLE
Shell Size - Insert 28-12
Shell Finish Olive Drab Cadmium
Current Rating 13A
Reach Compliance Code unknown
Ingress Protection Fluid Resistant
Shielding Unshielded
Orientation Y
Total Number of Contacts 26
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Threaded
Additional Feature STANDARD: MIL-C-5015, COMPATIBLE CONTACT: M39029/29-212
Gender Female
Applications Automotive, Military
Color Olive Drab
Number of Positions 26 (Power)
Connector Type Receptacle, Male Pins
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Military, MIL-DTL-5015
Published 2006
Packaging Bulk
Operating Temperature -55°C~175°C
Physical
Shell Material Aluminum
Number of Pins 16
Mounting Feature Flange
Mounting Type Panel Mount
Mount Flanges, Panel
Contact Plating Silver
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 16 Weeks
