MS3450W16-9P
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Circular MIL Spec Connector 4P MS Series MIL-DTL-5015
PDF
/
Inventory: 5676
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Fluid Resistant
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Technical
Wire Gauge (Min) 14 AWG
Wire Gauge (Max) 12 AWG
Plating Cadmium
Backshell Type SOLID
Empty Shell NO
Contact Gender Male
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 4
Shell Size - Insert 16-9
Shell Finish Olive Drab Cadmium
Military Standard MIL-DTL-5015
Current Rating 23A
Ingress Protection Fluid Resistant
Shielding Unshielded
Orientation N (Normal)
Current Rating (Amps) 13A 23A
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Threaded
Additional Feature STANDARD: MIL-C-5015, COMPATIBLE CONTACTS: M39029/29-213; M39029/29-212
Voltage - Rated 2kV
Gender Female
Applications Automotive, Military
Color Olive Drab
Number of Positions 4 (Power)
Connector Type Receptacle, Male Pins
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Military, MIL-DTL-5015
Published 2006
Packaging Bulk
Operating Temperature -55°C~175°C
Physical
Shell Material Aluminum
Number of Pins 16
Mounting Feature Flange
Mounting Type Panel Mount
Mount Flanges, Panel, Wall
Contact Plating Silver
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 16 Weeks
