MS3450L22-6SX
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
STANDARD: MIL-DTL-5015POLARIZED Circular Connector
PDF
/
Inventory: 2722
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Mount Flanges, Panel, Wall
Mounting Type Panel Mount
Mounting Feature Flange
Shell Material Aluminum
Technical
Operating Temperature -55°C~200°C
Packaging Bulk
Series Military, MIL-DTL-5015
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
Connector Type Receptacle, Female Sockets
Number of Positions 3 (Power)
Color Silver
Applications Automotive, Military
Gender Female
Additional Feature STANDARD: MIL-DTL-5015, POLARIZED
Fastening Type Threaded
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts YES
Option GENERAL PURPOSE
Current Rating (Amps) 13A 46A
Orientation X
Shielding Unshielded
Ingress Protection Fluid Resistant
Shell Finish Electroless Nickel
Shell Size - Insert 22-6
Number of Contacts 3
Mating Information MULTIPLE MATING PARTS AVAILABLE
Empty Shell NO
Backshell Type SOLID
Environmental Characteristics ENVIRONMENT/FLUID/IMMERSION RESISTANT
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Ratings Fluid Resistant
