MS3450L20-14S
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Circular MIL Spec Connector 5P MS Series MIL-DTL-5015
PDF
/
Buying Options
Total Price: USD $59.41
Unit Price: USD $59.4088
≥1 USD $59.4088
≥10 USD $57.5784
≥100 USD $55.8624
≥500 USD $54.2432
≥1000 USD $51.9816
≥3000 USD $51.2688
Inventory: 70
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Mount Flanges, Panel, Wall
Mounting Type Panel Mount
Mounting Feature Flange
Shell Material Aluminum
Technical
Operating Temperature -55°C~200°C
Packaging Bulk
Published 2005
Series Military, MIL-DTL-5015
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
Connector Type Receptacle, Female Sockets
Number of Positions 5 (Power)
Color Silver
Applications Automotive, Military
Voltage - Rated 2kV
Fastening Type Threaded
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts YES
Option GENERAL PURPOSE
Current Rating (Amps) 23A 46A
Orientation N (Normal)
Shielding Unshielded
Ingress Protection Fluid Resistant
Depth 38.1mm
Current Rating 46A
Military Standard MIL-DTL-5015
Shell Finish Electroless Nickel
Shell Size - Insert 20-14
Number of Contacts 5
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Gender Female
Empty Shell NO
Backshell Type SOLID
Environmental Characteristics ENVIRONMENT/FLUID/IMMERSION RESISTANT
Plating Electroless Nickel
Wire Gauge (Max) 8 AWG
Wire Gauge (Min) 10 AWG
Dimensions
Length 63.5mm
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Ratings Fluid Resistant
