MS27656T25F37P
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
AMPHENOL INDUSTRIAL MS27656T25F37P Circular Connector, MIL-DTL-38999 Series I, Wall Mount Receptacle, 37, Crimp Pin, Bayonet, 25-37
PDF
/
Inventory: 4588
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Mount Wall
Mounting Type Panel Mount
Mounting Feature Flange
Shell Material Aluminum Alloy
Body Material Aluminium
Technical
Operating Temperature -65°C~200°C
Packaging Bulk
Published 2006
Series Military, MIL-DTL-38999 Series I, LJT
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Receptacle, Male Pins
Number of Positions 37
Color Silver
Applications Aviation, Marine, Military
Gender Receptacle
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
Orientation N (Normal)
Shielding Unshielded
Ingress Protection Environment Resistant
Depth 46.02mm
Military Standard MIL-DTL-38999
Shell Finish Electroless Nickel
Shell Size - Insert 25-37
Contact Gender Male
Contact Style Pin
Plating Electroless Nickel, Nickel
Body Plating Electroless Nickel
Dimensions
Length 32.35mm
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
