MS27656P13B8SA
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
CIRCULAR, SIZE 13, 8WAYS, SKT
PDF
/
Inventory: 1971
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Technical
Contact Style Socket
Backshell Type SOLID
Empty Shell NO
Shell Size - Insert 13-8
Shell Finish Olive Drab Cadmium over Nickel
Shielding Unshielded
Orientation A
Total Number of Contacts 8
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
Gender Receptacle
Applications Aviation, Marine, Military
Color Olive Drab
Number of Positions 8
Connector Type Receptacle, Female Sockets
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
Feature Potted
Series Military, MIL-DTL-38999 Series I, LJT
Published 2006
Packaging Bulk
Operating Temperature -65°C~175°C
Physical
Body Material Aluminium
Shell Material Aluminum Alloy
Mounting Feature Flange
Mounting Type Panel Mount
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 8 Weeks
