MS27656E19B32S
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
AMPHENOL INDUSTRIAL MS27656E19B32S CONNECTOR, CIRCULAR, 32WAY, SIZE 19
PDF
/
Inventory: 5504
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Environment Resistant
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Length 32.33mm
Technical
Plating Cadmium
Contact Style Socket
Backshell Type SOLID
Empty Shell NO
Contact Gender Female
Shell Size - Insert 19-32
Shell Finish Olive Drab Cadmium over Nickel
Military Standard MIL-DTL-38999
Current Rating 7.5A
Depth 36.52mm
Ingress Protection Environment Resistant
Shielding Unshielded
Orientation N (Normal)
Total Number of Contacts 32
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
Gender Receptacle
Applications Aviation, Military
Color Olive Drab
Number of Positions 32
Connector Type Receptacle, Female Sockets
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
Feature Shielded
JESD-609 Code e4
Series Military, MIL-DTL-38999 Series I, LJT
Published 2006
Packaging Bulk
Operating Temperature -65°C~175°C
Physical
Body Material Aluminium
Shell Material Aluminum
Mounting Feature Flange
Mounting Type Panel Mount
Mount Flanges, Panel, Wall
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 16 Weeks
