MS27513E12A3P
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
AMPHENOL MS27513E12A3P Circular Connector, MIL-DTL-38999 Series II, Box Mount Receptacle, 3, Crimp Pin, Bayonet, 12-3
PDF
/
Inventory: 9244
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material Copper Alloy
Mounting Type Panel Mount
Mounting Feature Flange
Shell Material Aluminum Alloy
Body Material Aluminium
Technical
Operating Temperature -65°C~175°C
Packaging Bulk
Published 2006
Series Military, MIL-DTL-38999 Series II, JT
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Receptacle, Male Pins
Number of Positions 3
Applications Aviation, Marine, Military
Gender Female
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
Orientation N (Normal)
Shielding Unshielded
Depth 26.18mm
Reach Compliance Code unknown
Military Standard MIL-DTL-38999
Shell Finish Cadmium over Nickel
Shell Size - Insert 12-3
Contact Style Pin
Body Plating Cadmium
Dimensions
Length 22.75mm
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
