MS27508E24B29PC
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Olive Drab Cadmium over Nickel Military MIL-DTL-38999Series II JT Non-RoHS Compliant Environment Resistant Circular Connector 16AWG -65C~200C 13A 850V
PDF
/
Inventory: 4619
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Environment Resistant
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Technical
Wire/Cable Gauge 16 AWG
Plating Cadmium
Contact Style Pin
Backshell Type SOLID
Empty Shell NO
Contact Gender Male
Shell Size - Insert 24-29
Shell Finish Olive Drab Cadmium over Nickel
Military Standard MIL-DTL-38999
Current Rating 13A
Ingress Protection Environment Resistant
Shielding Unshielded
Orientation C
Total Number of Contacts 29
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
Voltage - Rated 850V
Gender Female
Applications Aviation, Military
Color Olive Drab
Number of Positions 29
Connector Type Receptacle, Male Pins
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
Series Military, MIL-DTL-38999 Series II, JT
Published 2006
Packaging Bulk
Operating Temperature -65°C~200°C
Physical
Shell Material Aluminum
Mounting Feature Flange
Mounting Type Panel Mount
Mount Box, Flanges, Panel
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 16 Weeks
