MS27508E18A32SC
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Connector
PDF
/
Inventory: 3999
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Mount Flanges, Panel
Mounting Type Panel Mount
Mounting Feature Flange
Shell Material Aluminum
Technical
Operating Temperature -65°C~200°C
Packaging Bulk
Published 2014
Series Military, MIL-DTL-38999 Series II, JT
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Receptacle, Female Sockets
Number of Positions 32
Applications Aviation, Military
Gender Female
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 32
Orientation C
Shielding Unshielded
Ingress Protection Environment Resistant
Current Rating 7.5A
Shell Finish Cadmium over Nickel
Shell Size - Insert 18-32
Empty Shell NO
Backshell Type SOLID
Contact Style Socket
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
RoHS Status Non-RoHS Compliant
Ratings Environment Resistant
