MS27508E16F6SC
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
AMPHENOL MS27508E16F6SC Circular Connector, MIL-C-38999 Series II, Receptacle, 6, Socket, Crimp, Panel
PDF
/
Inventory: 3158
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Length 17.06mm
Technical
Plating Electroless Nickel, Passivated, Steel
Contact Style Socket
Backshell Type SOLID
Empty Shell NO
Contact Gender Female
Shell Size - Insert 16-6
Shell Finish Electroless Nickel
Military Standard MIL-DTL-38999
Depth 30.96mm
Ingress Protection Environment Resistant
Shielding Unshielded
Orientation C
Total Number of Contacts 6
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
Gender Receptacle
Applications Aviation, Marine, Military
Color Silver
Number of Positions 6
Connector Type Receptacle, Female Sockets
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
Series Military, MIL-DTL-38999 Series II, JT
Published 2006
Packaging Bulk
Operating Temperature -65°C~200°C
Physical
Body Material Aluminium
Shell Material Aluminum Alloy
Mounting Feature Flange
Mounting Type Panel Mount
Mount Box
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 13 Weeks
