MS27508E10B13PC
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Conn MIL-DTL-38999 Circular PIN 13 POS Crimp ST Box Mount 13 Terminal 1 Port
PDF
/
Inventory: 2271
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Technical
Contact Style Pin
Backshell Type SOLID
Empty Shell NO
Shell Size - Insert 10-13
Shell Finish Olive Drab Cadmium over Nickel
Ingress Protection Environment Resistant
Shielding Unshielded
Orientation C
Total Number of Contacts 13
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
Gender Female
Applications Aviation, Marine, Military
Color Olive Drab
Number of Positions 13
Connector Type Receptacle, Male Pins
Termination Crimp
Part Status Active
Pbfree Code no
Series Military, MIL-DTL-38999 Series II, JT
Published 2006
Packaging Bulk
Operating Temperature -65°C~175°C
Physical
Shell Material Aluminum Alloy
Mounting Feature Flange
Mounting Type Panel Mount
Mount Box
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 16 Weeks
