MS27505E17B8SD
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
CONN RCPT FMALE 8POS GOLD CRIMP
PDF
/
Inventory: 7855
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Ratings Environment Resistant
Technical
Contact Style Socket
Number of Contacts 8
Shell Size - Insert 17-8
Shell Finish Olive Drab Cadmium over Nickel
Current Rating 13A
Ingress Protection Environment Resistant
Shielding Unshielded
Orientation D
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
Gender Female
Applications Aviation, Military
Color Olive Drab
Min Operating Temperature -65°C
Max Operating Temperature 175°C
Number of Positions 8
Connector Type Receptacle, Female Sockets
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Shielded
Series Military, MIL-DTL-38999 Series I, LJT
Published 2006
Packaging Bulk
Operating Temperature -65°C~175°C
Physical
Shell Material Aluminum
Mounting Feature Flange
Mounting Type Panel Mount
Mount Box, Flanges, Panel
Contact Plating Gold
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 16 Weeks
