MS27500E16A35S
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Conn Subminiature Cylindrical SKT 55 POS Crimp RA Cable Mount 55 Terminal 1 Port
PDF
/
Inventory: 3421
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Environment Resistant
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Length 57.32mm
Technical
Cable Opening 0.238 ~ 0.634 (6.05mm ~ 16.10mm)
Plating Cadmium
Contact Style Socket
Backshell Type SOLID
Empty Shell NO
Shell Size - Insert 16-35
Shell Finish Cadmium over Nickel
Current Rating 5A
Ingress Protection Environment Resistant
Shielding Unshielded
Orientation N (Normal)
Total Number of Contacts 55
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
Additional Feature STANDARD: MIL-DTL-38999, COMPATIBLE CONTACT: M39029/57-354
Gender Male
Applications Aviation, Military
Number of Positions 55
Connector Type Plug, Female Sockets
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
Feature Cable Clamp, Coupling Nut
Series Military, MIL-DTL-38999 Series II, JT
Packaging Bulk
Operating Temperature -65°C~200°C
Physical
Shell Material Aluminum
Mounting Type Free Hanging (In-Line), Right Angle
Mount Cable, Free Hanging
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 16 Weeks
