MS27499E20F16S
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
STANDARD: MIL-DTL-38999COMPATIBLE CONTACT: M39029/57-358 Circular Connector
PDF
/
Inventory: 7824
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Mount Box
Mounting Type Panel Mount
Mounting Feature Flange
Shell Material Aluminum Alloy
Technical
Operating Temperature -65°C~200°C
Packaging Bulk
Published 2006
Series Military, MIL-DTL-38999 Series II, JT
JESD-609 Code e4
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Receptacle, Female Sockets
Number of Positions 16
Color Silver
Applications Aviation, Marine, Military
Gender Female
Additional Feature STANDARD: MIL-DTL-38999, COMPATIBLE CONTACT: M39029/57-358
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 16
Orientation N (Normal)
Shielding Unshielded
Ingress Protection Environment Resistant
Shell Finish Electroless Nickel
Shell Size - Insert 20-16
Empty Shell NO
Backshell Type SOLID
Contact Style Socket
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
