MS27499E16B6SC
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Conn Subminiature Cylindrical SKT 6 POS Crimp ST Box Mount 6 Terminal 1 Port
PDF
/
Buying Options
Total Price: USD $225.44
Unit Price: USD $225.435625
≥1 USD $225.435625
≥10 USD $212.675122
≥100 USD $200.636908
≥500 USD $189.280102
≥1000 USD $178.566125
Inventory: 6859
Minimum: 1
-
+
Technical Details
Compliance
Ratings Environment Resistant
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Length 16.91mm
Technical
Plating Cadmium
Contact Style Socket
Contact Gender Female
Number of Contacts 6
Shell Size - Insert 16-6
Shell Finish Olive Drab Cadmium over Nickel
Military Standard MIL-DTL-38999
Current Rating 23A
Depth 30.96mm
Ingress Protection Environment Resistant
Shielding Unshielded
Orientation C
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
Gender Female
Applications Aviation, Military
Color Olive Drab
Min Operating Temperature -65°C
Max Operating Temperature 200°C
Number of Positions 6
Connector Type Receptacle, Female Sockets
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Military, MIL-DTL-38999 Series II, JT
Published 2006
Packaging Bulk
Operating Temperature -65°C~200°C
Physical
Shell Material Aluminum
Mounting Feature Flange
Mounting Type Panel Mount
Mount Box, Flanges, Panel
Contact Plating Gold
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 16 Weeks
