MS27497T8F35SD
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
AMPHENOL MS27497T8F35SD CIRCULAR, SIZE 8, 6WAYS, SKT
PDF
/
Inventory: 2377
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Length 22.47mm
Technical
Plating Electroless Nickel
Contact Style Socket
Empty Shell NO
Shell Size - Insert 8-35
Shell Finish Electroless Nickel
Depth 20.62mm
Ingress Protection Environment Resistant
Shielding Unshielded
Orientation D
Total Number of Contacts 6
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
Gender Receptacle
Applications Aviation, Marine, Military
Color Silver
Number of Positions 6
Connector Type Receptacle, Female Sockets
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
JESD-609 Code e4
Series Military, MIL-DTL-38999 Series II, JT
Published 2006
Packaging Bulk
Operating Temperature -65°C~200°C
Physical
Body Material Aluminium
Shell Material Aluminum Alloy
Mounting Feature Flange
Mounting Type Panel Mount
Mount Wall
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 10 Weeks
