MS27497P14B97PB
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
JT 12C 8#20 4#16 PIN RECP
PDF
/
Inventory: 8829
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Contact Material Copper Alloy
Mounting Type Panel Mount
Mounting Feature Flange
Number of Pins 16
Shell Material Aluminum Alloy
Technical
Operating Temperature -65°C~175°C
Packaging Bulk
Published 2014
Series Military, MIL-DTL-38999 Series II, JT
Feature Potted
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Receptacle, Male Pins
Number of Positions 12
Color Olive Drab
Applications Aviation, Marine, Military
Gender Female
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
Orientation B
Shielding Unshielded
Reach Compliance Code unknown
Shell Finish Olive Drab Cadmium over Nickel
Shell Size - Insert 14-97
Contact Style Pin
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
RoHS Status Non-RoHS Compliant
