MS27497E24A61SD
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
CONN RCPT FMALE 61POS GOLD CRIMP
PDF
/
Inventory: 2314
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Environment Resistant
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Technical
Contact Style Socket
Empty Shell NO
Shell Size - Insert 24-61
Shell Finish Cadmium over Nickel
Current Rating 7.5A
Ingress Protection Environment Resistant
Shielding Unshielded
Orientation D
Total Number of Contacts 61
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
Gender Female
Applications Aviation, Military
Number of Positions 61
Connector Type Receptacle, Female Sockets
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
JESD-609 Code e4
Series Military, MIL-DTL-38999 Series II, JT
Published 2014
Packaging Bulk
Operating Temperature -65°C~200°C
Physical
Shell Material Aluminum
Mounting Feature Flange
Mounting Type Panel Mount
Mount Flanges, Panel, Wall
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 16 Weeks
