MS27497E12A4S
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
AMPHENOL MS27497E12A4S CIRCULAR, SIZE 12, 4WAYS, SKT
PDF
/
Buying Options
Total Price: USD $106.04
Unit Price: USD $106.035688
≥1 USD $106.035688
≥10 USD $100.033666
≥100 USD $94.371384
≥500 USD $89.029604
≥1000 USD $83.990193
Inventory: 7663
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Contact Material Copper Alloy
Mount Wall
Mounting Type Panel Mount
Mounting Feature Flange
Shell Material Aluminum Alloy
Body Material Aluminium
Technical
Operating Temperature -65°C~175°C
Packaging Bulk
Published 2006
Series Military, MIL-DTL-38999 Series II, JT
JESD-609 Code e4
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
Connector Type Receptacle, Female Sockets
Number of Positions 4
Applications Aviation, Marine, Military
Gender Receptacle
Additional Feature STANDARD: MIL-DTL-38999, COMPATIBLE CONTACT: M39029/57-358
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 4
Orientation N (Normal)
Shielding Unshielded
Ingress Protection Environment Resistant
Shell Finish Cadmium over Nickel
Shell Size - Insert 12-4
Empty Shell NO
Backshell Type SOLID
Contact Style Socket
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
