MS27484T16F8PC
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
CONNECTOR, CIRCULAR, 16-8, 8WAY, SIZE 16
PDF
/
Inventory: 7259
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Mount Cable
Mounting Type Free Hanging (In-Line)
Shell Material Aluminum Alloy
Body Material Aluminium
Technical
Operating Temperature -65°C~200°C
Packaging Bulk
Published 2006
Series Military, MIL-DTL-38999 Series II, JT
Feature Coupling Nut, Ground
Pbfree Code no
Part Status Active
Termination Crimp
Connector Type Plug, Male Pins
Number of Positions 8
Color Silver
Applications Aviation, Marine, Military
Gender Male
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 8
Orientation C
Shielding Shielded
Ingress Protection Environment Resistant
Shell Finish Electroless Nickel
Shell Size - Insert 16-8
Empty Shell NO
Backshell Type SOLID
Contact Style Pin
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
