MS27484E24A35PA
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Cadmium over Nickel Military MIL-DTL-38999Series II JT Non-RoHS Compliant Environment Resistant Circular Connector -65C~200C 5A 50.0muin 1.27mum
PDF
/
Inventory: 6463
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Environment Resistant
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Length 23.82mm
Technical
Plating Cadmium
Contact Style Pin
Backshell Type SOLID
Empty Shell NO
Shell Size - Insert 24-35
Shell Finish Cadmium over Nickel
Current Rating 5A
Ingress Protection Environment Resistant
Shielding Shielded
Orientation A
Total Number of Contacts 128
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
Gender Male
Applications Aviation, Military
Number of Positions 128
Connector Type Plug, Male Pins
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
Feature Coupling Nut, Ground
JESD-609 Code e4
Series Military, MIL-DTL-38999 Series II, JT
Packaging Bulk
Operating Temperature -65°C~200°C
Physical
Shell Material Aluminum
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 16 Weeks
