MS27484E22F55PA
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Electroless Nickel Military MIL-DTL-38999Series II JT Non-RoHS Compliant Environment Resistant Circular Connector -65C~200C 7.5A 50.0muin 1.27mum
PDF
/
Inventory: 9256
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Aluminum
Technical
Operating Temperature -65°C~200°C
Packaging Bulk
Published 2006
Series Military, MIL-DTL-38999 Series II, JT
JESD-609 Code e4
Feature Coupling Nut, Ground
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Plug, Male Pins
Number of Positions 55
Color Silver
Applications Aviation, Military
Gender Male
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Total Number of Contacts 55
Orientation A
Shielding Shielded
Ingress Protection Environment Resistant
Current Rating 7.5A
Shell Finish Electroless Nickel
Shell Size - Insert 22-55
Empty Shell NO
Backshell Type SOLID
Contact Style Pin
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Ratings Environment Resistant
