MS27484E14B5SD
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
CONNECTOR, CIRCULAR, 14-5, 5WAY, SIZE 14
PDF
/
Inventory: 985
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Aluminum
Body Material Aluminium
Technical
Operating Temperature -65°C~200°C
Packaging Bulk
Published 2006
Series Military, MIL-DTL-38999 Series II, JT
Feature Coupling Nut, Ground
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Plug, Female Sockets
Number of Positions 5
Color Olive Drab
Applications Aviation, Military
Gender Male
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 5
Orientation D
Shielding Shielded
Ingress Protection Environment Resistant
Current Rating 13A
Shell Finish Olive Drab Cadmium over Nickel
Shell Size - Insert 14-5
Empty Shell NO
Contact Style Socket
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
Ratings Environment Resistant
