MS27484E14B18SB
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
JT8C 18#20 SKT PLUG
PDF
/
Buying Options
Total Price: USD $129.77
Unit Price: USD $129.769247
≥1 USD $129.769247
≥10 USD $122.423824
≥100 USD $115.494169
≥500 USD $108.956767
≥1000 USD $102.789399
Inventory: 2408
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Technical
Contact Style Socket
Backshell Type SOLID
Empty Shell NO
Shell Size - Insert 14-18
Shell Finish Olive Drab Cadmium over Nickel
Ingress Protection Environment Resistant
Shielding Shielded
Orientation B
Total Number of Contacts 18
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
Gender Male
Applications Aviation, Marine, Military
Color Olive Drab
Number of Positions 18
Connector Type Plug, Female Sockets
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
Feature Coupling Nut, Ground
JESD-609 Code e4
Series Military, MIL-DTL-38999 Series II, JT
Published 2006
Packaging Bulk
Operating Temperature -65°C~175°C
Physical
Shell Material Aluminum Alloy
Mounting Type Free Hanging (In-Line)
Mount Cable
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 12 Weeks
