MS27484E12A3S
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Conn Subminiature Cylindrical SKT 3 POS Crimp ST Cable Mount 3 Terminal 1 Port
PDF
/
Buying Options
Total Price: USD $155.04
Unit Price: USD $155.04384
≥1 USD $155.04384
≥10 USD $146.267775
≥100 USD $137.98846
≥500 USD $130.177801
≥1000 USD $122.809249
Inventory: 3790
Minimum: 1
-
+
Technical Details
Compliance
Ratings Environment Resistant
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Technical
Plating Cadmium
Contact Style Socket
Backshell Type SOLID
Empty Shell NO
Contact Gender Female
Shell Size - Insert 12-3
Shell Finish Cadmium over Nickel
Military Standard MIL-DTL-38999
Current Rating 13A
Ingress Protection Environment Resistant
Shielding Shielded
Orientation N (Normal)
Total Number of Contacts 3
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
Gender Male
Applications Aviation, Military
Number of Positions 3
Connector Type Plug, Female Sockets
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
Feature Coupling Nut, Ground
JESD-609 Code e4
Series Military, MIL-DTL-38999 Series II, JT
Published 2006
Packaging Bulk
Operating Temperature -65°C~200°C
Physical
Body Material Aluminium
Shell Material Aluminum
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 16 Weeks
