MS27474T20B1P
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Conn Subminiature Cylindrical PIN 79 POS Crimp ST Jam Nut 79 Terminal 1 Port
PDF
/
Inventory: 8773
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Length 22.5mm
Technical
Plating Cadmium
Contact Style Pin
Number of Contacts 79
Shell Size - Insert 20-1
Shell Finish Olive Drab Cadmium over Nickel
Depth 51.2mm
Ingress Protection Environment Resistant
Shielding Unshielded
Orientation N (Normal)
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
Gender Male
Applications Aviation, Marine, Military
Color Olive Drab
Min Operating Temperature -65°C
Max Operating Temperature 200°C
Number of Positions 79
Connector Type Receptacle, Male Pins
Termination Crimp
Part Status Active
Series Military, MIL-DTL-38999 Series II, JT
Packaging Bulk
Operating Temperature -65°C~175°C
Physical
Shell Material Aluminum Alloy
Mounting Feature Bulkhead - Front Side Nut
Mounting Type Panel Mount
Mount Jam Nut
Contact Plating Gold
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 16 Weeks
