MS27474T10A5P
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Conn Subminiature Cylindrical PIN 5 POS Crimp ST Jam Nut 5 Terminal 1 Port
PDF
/
Inventory: 6854
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Environment Resistant
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Length 22.63mm
Technical
Plating Cadmium
Contact Style Pin
Contact Gender Male
Number of Contacts 5
Shell Size - Insert 10-5
Shell Finish Cadmium over Nickel
Military Standard MIL-DTL-38999
Current Rating 7.5A
Depth 34.92mm
Ingress Protection Environment Resistant
Shielding Unshielded
Orientation N (Normal)
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
Gender Male
Applications Aviation, Military
Min Operating Temperature -65°C
Max Operating Temperature 200°C
Number of Positions 5
Connector Type Receptacle, Male Pins
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Military, MIL-DTL-38999 Series II, JT
Published 2015
Packaging Bulk
Operating Temperature -65°C~200°C
Physical
Shell Material Aluminum
Mounting Feature Bulkhead - Front Side Nut
Mounting Type Panel Mount
Mount Bulkhead, Front Side Nut, Jam Nut, Panel
Contact Plating Gold
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 16 Weeks
