MS27474E24B4PB
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Conn Subminiature Cylindrical PIN 56 POS Crimp ST Jam Nut 56 Terminal 1 Port
PDF
/
Inventory: 4833
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Mount Bulkhead, Front Side Nut, Panel
Mounting Type Panel Mount
Mounting Feature Bulkhead - Front Side Nut
Shell Material Aluminum
Technical
Operating Temperature -65°C~200°C
Packaging Bulk
Published 2006
Series Military, MIL-DTL-38999 Series II, JT
JESD-609 Code e4
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Receptacle, Male Pins
Number of Positions 56
Color Olive Drab
Applications Aviation, Military
Gender Male
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 56
Orientation B
Shielding Unshielded
Ingress Protection Environment Resistant
Depth 57.53mm
Current Rating 13A
Shell Finish Olive Drab Cadmium over Nickel
Shell Size - Insert 24-4
Empty Shell NO
Backshell Type SOLID
Contact Style Pin
Plating Cadmium
Dimensions
Length 23.69mm
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
RoHS Status Non-RoHS Compliant
Ratings Environment Resistant
