MS27473E20F41PA
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Circular MIL Spec Connector 41P 20 SIZE STRAIGHT PLUG PIN
PDF
/
Buying Options
Total Price: USD $262.67
Unit Price: USD $262.673335
≥1 USD $262.673335
≥10 USD $247.805039
≥100 USD $233.778339
≥500 USD $220.5456
≥1000 USD $208.061879
Inventory: 2640
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Aluminum
Technical
Operating Temperature -65°C~200°C
Packaging Bulk
Published 2006
Series Military, MIL-DTL-38999 Series II, JT
JESD-609 Code e4
Feature Coupling Nut
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Plug, Male Pins
Number of Positions 41
Color Silver
Applications Aviation, Military
Voltage - Rated 850V
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Total Number of Contacts 41
Orientation A
Shielding Unshielded
Ingress Protection Environment Resistant
Current Rating 7.5A
Military Standard MIL-DTL-38999
Shell Finish Electroless Nickel
Shell Size - Insert 20-41
Contact Gender Male
Empty Shell NO
Backshell Type SOLID
Contact Style Pin
Plating Passivated, Steel
Wire/Cable Gauge 20 AWG
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Ratings Environment Resistant
