MS27473E12F3SA
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Electroless Nickel Military MIL-DTL-38999Series II JT Non-RoHS Compliant Environment Resistant Circular Connector -65C~200C 13A 50.0muin 1.27mum
PDF
/
Inventory: 3502
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Aluminum
Technical
Operating Temperature -65°C~200°C
Packaging Bulk
Published 2006
Series Military, MIL-DTL-38999 Series II, JT
JESD-609 Code e4
Feature Coupling Nut
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Plug, Female Sockets
Number of Positions 3
Color Silver
Applications Aviation, Military
Gender Male
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Total Number of Contacts 3
Orientation A
Shielding Unshielded
Ingress Protection Environment Resistant
Current Rating 13A
Military Standard MIL-DTL-38999
Shell Finish Electroless Nickel
Shell Size - Insert 12-3
Contact Gender Female
Empty Shell NO
Backshell Type SOLID
Contact Style Socket
Plating Passivated, Steel
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
RoHS Status Non-RoHS Compliant
Ratings Environment Resistant
