MS27472T14F35PC
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Electroless Nickel Military MIL-DTL-38999Series II JT Non-RoHS Compliant Environment Resistant Circular Connector -65C~200C 5A 28.57mm
PDF
/
Inventory: 1532
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Mount Flanges, Panel, Wall
Mounting Type Panel Mount
Mounting Feature Flange
Shell Material Aluminum
Technical
Operating Temperature -65°C~200°C
Packaging Bulk
Published 2006
Series Military, MIL-DTL-38999 Series II, JT
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Receptacle, Male Pins
Number of Positions 37
Color Silver
Applications Aviation, Military
Gender Female
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 37
Orientation C
Shielding Unshielded
Ingress Protection Environment Resistant
Depth 28.57mm
Current Rating 5A
Shell Finish Electroless Nickel
Shell Size - Insert 14-35
Empty Shell NO
Backshell Type SOLID
Contact Style Pin
Plating Electroless Nickel
Dimensions
Length 22.35mm
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Ratings Environment Resistant
