MS27468T25F24S
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
AMPHENOL MS27468T25F24S CIRCULAR, SIZE 25, 24WAYS, SKT
PDF
/
Inventory: 8282
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Mount Bulkhead, Front Side Nut, Jam Nut, Panel
Mounting Type Panel Mount
Mounting Feature Bulkhead - Front Side Nut
Shell Material Aluminum
Body Material Aluminium
Technical
Operating Temperature -65°C~200°C
Packaging Bulk
Published 2006
Series Military, MIL-DTL-38999 Series I, LJT
JESD-609 Code e4
Feature Shielded
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Receptacle, Female Sockets
Number of Positions 24
Color Silver
Applications Aviation, Military
Gender Receptacle
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 24
Orientation N (Normal)
Shielding Unshielded
Ingress Protection Environment Resistant
Current Rating 23A
Military Standard MIL-DTL-38999
Shell Finish Electroless Nickel
Shell Size - Insert 25-24
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Gender Female
Empty Shell NO
Backshell Type SOLID
Contact Style Socket
Plating Passivated, Steel
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
Ratings Environment Resistant
