MS27468T23F55SD
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Electroless Nickel Military MIL-DTL-38999Series I LJT Non-RoHS Compliant Environment Resistant Circular Connector -65C~200C 7.5A 50.0muin 1.27mum
PDF
/
Inventory: 9679
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Mount Bulkhead, Front Side Nut, Jam Nut, Panel
Mounting Type Panel Mount
Mounting Feature Bulkhead - Front Side Nut
Shell Material Aluminum
Technical
Operating Temperature -65°C~200°C
Packaging Bulk
Published 2006
Series Military, MIL-DTL-38999 Series I, LJT
Feature Shielded
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Receptacle, Female Sockets
Number of Positions 55
Color Silver
Applications Aviation, Military
Gender Female
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 55
Orientation D
Shielding Unshielded
Ingress Protection Environment Resistant
Current Rating 7.5A
Shell Finish Electroless Nickel
Shell Size - Insert 23-55
Empty Shell NO
Contact Style Socket
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Ratings Environment Resistant
