MS27468T15B15PC
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
CIRCULAR, SIZE 15, 15WAYS, PIN
PDF
/
Inventory: 5064
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Contact Material Copper Alloy
Mount Jam Nut
Mounting Type Panel Mount
Mounting Feature Bulkhead - Front Side Nut
Shell Material Aluminum Alloy
Body Material Aluminium
Technical
Operating Temperature -65°C~175°C
Packaging Bulk
Published 2006
Series Military, MIL-DTL-38999 Series I, LJT
JESD-609 Code e4
Pbfree Code no
Part Status Active
Termination Crimp
Connector Type Receptacle, Male Pins
Number of Positions 15
Color Olive Drab
Applications Aviation, Marine, Military
Gender Receptacle
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 15
Orientation C
Shielding Unshielded
Ingress Protection Environment Resistant
Shell Finish Olive Drab Cadmium over Nickel
Shell Size - Insert 15-15
Mating Information MULTIPLE MATING PARTS AVAILABLE
Empty Shell NO
Backshell Type SOLID
Contact Style Pin
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
