MS27468E9B35PD image
Favorite
MS27468E9B35PD image
Favorite
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description CIRCULAR, SIZE 9, 6WAYS, PIN
PDF
/
Inventory: 4591
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC

Dimensions

Contact Finish Thickness - Mating 50.0μin 1.27μm

Technical

Shell Size, MIL A
Contact Style Pin
Empty Shell NO
Shell Size - Insert 9-35
Shell Finish Olive Drab Cadmium over Nickel
Ingress Protection Environment Resistant
Shielding Unshielded
Orientation D
Total Number of Contacts 6
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
Gender Receptacle
Applications Aviation, Marine, Military
Color Olive Drab
Number of Positions 6
Connector Type Receptacle, Male Pins
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
JESD-609 Code e4
Series Military, MIL-DTL-38999 Series I, LJT
Published 2006
Packaging Bulk
Operating Temperature -65°C~175°C

Physical

Body Material Aluminium
Shell Material Aluminum Alloy
Mounting Feature Bulkhead - Front Side Nut
Mounting Type Panel Mount
Contact Material Copper Alloy

Supply Chain

Factory Lead Time 8 Weeks
